Drolet Escape 1500-I Wood Insert with Faceplate DB03137

Drolet Escape 1500-I Wood Insert with Faceplate DB03137

SKU DB03137

by Drolet

Save $150.00

$1,999.00

$1,999.00 - $1,999.00

$1,999.00

$1,849.00

$1,849.00 - $1,849.00

$1,849.00

Availability:

in stock

Drolet Escape 1500-I Wood Insert with Faceplate DB03137 offers an eco-conscious and highly efficient solution for transforming your masonry fireplace into a powerful heat source. Designed to warm spaces up to 1,800 square feet, this EPA-certified wood insert delivers an impressive heat output of up to 65,000 BTU/h, with a clean burn rate of just 2.4 g/h of particulate emissions. It features a robust 5/16" steel top reinforced with stainless steel, ensuring long-lasting performance. The unit includes a full 29" x 44" faceplate, high-efficiency 144 CFM blower, ceramic glass door, and an ash lip for added convenience. With a 7-hour burn time and compatibility with 18-inch logs, the Escape 1500-I balances sustainability, power, and elegance—all proudly made in Canada.

Features:

Heats up to 1,800 sq. ft. with 65,000 BTU/h maximum output
EPA 2020 certified for low emissions (2.4 g/h)
Includes 29" x 44" faceplate and 144 CFM blower
Accommodates logs up to 18" with a 7-hour burn time
Durable construction with 5/16" top steel and ceramic glass
Non-catalytic combustion and stainless-steel secondary air system
Proudly made in Canada with a limited lifetime warranty
Weight: 360 lbs
Included: 29'' x 44'' faceplate, blower, ceramic glass, ash lip, air damper.

*Installation must be done according to the specifications and drawings detailed in the owner's manual.

A contact number is required for all Drolet, Century, and England's Stove Works orders at checkout

Not sure if this is the right stove?

Let our Wood Stove Picker find your perfect match.

Quantity

Specifications

Fuel type	Dry cordwood (16" recommended)
Recommended heating area (9)	500 - 1,800 ft²
Overall firebox volume	1.9 ft³
EPA loading volume	1.44 ft³
Maximum burn time (9)	6 h
Maximum heat output-dry cordwood (4)	65,000 BTU/h (19 kW)
Minimum overall heat output rate (4) (5)	15,650 BTU/h (4.6 kW)
Maximum overall heat output rate (4) (5)	23,300 BTU/h (6.83 kW)
Average overall efficiency-dry cordwood (HHV) (5) (6)	70 %
Average overall efficiency-dry cordwood (LHV) (5) (7)	75 %
Optimum efficiency (1) (2)	78 %
Optimum heat transfer efficiency (8)	74 %
Average particulate emission rate (3)	1.26 g/h
Average CO (10)	58 g/h
Size	Medium
Premium quality blower included (CFM)	144 CFM included
Certified according to applicable standards	By an accredited laboratory (CAN/USA)
Combustion technology	Non-catalytic
Stainless-steel secondary-air system	Yes
Flue outlet diameter	6"
Distance-center of the flue outlet to back unit	5 3/4"
Distance-center of the flue outlet to side unit	12 3/4"
Chimney diameter	6"
Type of chimney	Liner - ULC-S635, CAN/ULC-S640, UL1777
Minimum chimney height	12'
Overall dimension (Width)	27 1/4"
Overall dimension (Height)	21 1/4"
Overall dimension (Depth)	22 3/8"
Door type	Single, glass with cast iron frame
Door opening size (Width)	17 1/4"
Door opening size (Height)	8 3/4"
Glass type	Ceramic glass
Glass surface - W x H	15 3/4" x 9 3/4"
Firebox size (Width)	19 5/8"
Firebox size (Height)	11 7/8"
Firebox size (Depth)	13 1/2"
Maximum log length	18"
Log positioning	Loading over width
Firebox lined with refractory bricks	Yes
Baffle type	High quality vermiculite
Minimum fireplace opening (Height)	21 1/2"
Minimum fireplace opening (Width)	27 1/2"
Minimum fireplace opening (Depth)	12 3/4"
High-efficiency certified appliance	Yes, EPA 2020 approved
Canadian Standard (emissions)	CSA B415.1-10
USA Standard (emissions)	EPA
Canadian Standard (safety)	ULC S628
USA Standard (safety)	UL 1482, UL 737
Steel thickness-body	3/16"
Steel thickness-top	5/16"
Warranty	Limited lifetime
Shipping weight	360 lb (163 kg)

1. Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.
2. Optimum overall efficiency at a specific burn rate (LHV).
3. This appliance is officially tested and certified by an independent agency.
4. The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.
5. As measured per CSA B415.1-10 stack loss method.
6. Higher Heating Value of the fuel.
7. Lower Heating Value of the fuel.
8. The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the solid fuels into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.
9. Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.
10. Carbon monoxyde.

Clearance to Combustibles

See user manual for other installation requirements.

	Canada	United States
Clearance - Combustible side wall to unit	16"	16"
Clearance - Combustible side mantle to unit	9"	9"
Clearance - Combustible top mantle to unit	27"	27"
Clearance - Top of the unit to a 12" combustible mantle shelf	27"	27"
Clearance - Base of the unit to ceiling**	84"	84"

*The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

**Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
