Enerzone Solution 3.5 Wood Insert Bundle

SKU EB00062-AC01229-OA10125
Original price $4,369.00 - Original price $4,469.00
Original price
$4,369.00
$4,369.00 - $4,469.00
Current price $4,369.00
Availability:
in stock
Availability:
in stock
Availability:
in stock
Availability:
in stock

The Enerzone Solution 3.5 Wood Insert Bundle is designed to transform your old masonry fireplace into a highly efficient heating solution, perfect for large spaces ranging from 1,000 to 2,700 square feet. With its advanced non-catalytic secondary combustion system, this wood insert not only delivers exceptional warmth but also offers a mesmerizing view of rolling flames through its expansive glass surface. Environmentally conscious and performance-driven, this insert promises comfort and economy while enhancing your winter ambiance. Customize your setup with a choice of faceplates, trims, and an optional firescreen to enjoy the full experience of a crackling wood fire.

Delivery time / Order Processing & Shipping Times

Rise ships manufacturer direct. We work hard so you receive your product(s) as quickly as possible. Learn more about our order processing & shipping times here.

Specifications

Fuel typeDry cordwood (16" recommended)
Recommended heating area1,000 - 2,700 ft²
Overall firebox volume3.5 ft³
EPA loading volume2.88 ft³
Maximum burn time10 h
Maximum heat output (dry cordwood)110,000 BTU/h (32.2 kW)
Minimum overall heat output rate17,200 BTU/h (5.0 kW)
Mobile home approvedNo
Premium quality blower included144 CFM included
Certified according to standardsBy an accredited laboratory (CAN/USA)
Combustion technologyNon-catalytic
Stainless-steel secondary-air systemYes
Flue outlet diameter6"
Distance - center of flue outlet to back unit7 1/8"
Distance - center of flue outlet to side unit14 3/8"
Recommended chimney diameter6"
Type of chimneyLiner - ULC-S635, CAN/ULC-S640, UL1777
Minimum chimney height12'
Overall dimensions (W x H x D)30 3/8" x 24 7/8" x 29 1/2"
Door typeSingle, glass with cast iron frame
Door opening size (W x H)19" x 10 5/8"
Glass typeCeramic glass
Glass surface (W x H)18 3/4" x 12 1/2"
Maximum overall heat output rate57,800 BTU/h (16.9 kW)
Average overall efficiency (HHV)71%
Average overall efficiency (LHV)76%
Optimum efficiency77%
Optimum heat transfer efficiency75%
Average particulate emission rate1.6 g/h
Average CO73 g/h
Steel thickness - body3/16"
Steel thickness - top3/8"
Firebox size (W x H x D)22 7/8" x 12 7/8" x 20 1/8"
Maximum log length22"
Log positioningLoading over width
Firebox lined with refractory bricksYes
Baffle typeC-Cast or equivalent
Minimum fireplace opening (W x H x D)31" x 26 1/4" x 18 3/8"
High-efficiency certified applianceYes, EPA 2020 approved
Canadian Standard (emissions)CSA B415.1-10
USA Standard (emissions)EPA
Canadian Standard (safety)ULC S628
USA Standard (safety)UL 1482, UL 737
WarrantyLimited lifetime
Shipping weight562 lb (255 kg)





 CanadaUnited States
Combustible side wall to unit19"19"
Combustible side mantle to unit9"9"
Combustible top mantle to unit27"27"
Top of the unit to a 12" combustible mantle shelf27"27"
Base of the unit to ceiling**84"84"
